Khoom Taw Qhia

Tsawg-Kev ceev submersible tov khoom siv dej khib nyiab kho yog tsim rau cov pas dej sib txawv thiab oxidation ditches, qis-ceev submersible tov khoom dej khib nyiab kho muaj txoj kab uas hla loj, thiab sib tov ceev yog tsawg, uas tuaj yeem tsim muaj zog thiab muaj peev xwm txaus. Qhov qis-ceev submersible tov khoom siv dej khib nyiab tuaj yeem tswj tau qhov ua kom zoo nrog cov kua qis qis- nrawm los tsim cov dej ntws. Ntxiv rau kev thawb thiab tsim cov dej ntws, qis -ceev submersible tov khoom kho dej khib nyiab kuj muaj kev sib xyaw ua haujlwm zoo.

Product Video

Daim ntawv thov

Kev kho dej phwj tuaj:Tsawg-Speed submersible tov khoom yuav siv tau nyob rau hauv sedimentation tanks, aeration tanks, thiab cov tshuaj tiv thaiv tanks ntawm cov dej phwj tuaj kho cov nroj tsuag

Kev kho dej khib nyiab:Nyob rau hauv cov txheej txheem kev lag luam thiab tshuaj lom neeg cov dej khib nyiab kho, qis -kev sib tw submersible ceev tuaj yeem txhawb cov kua dej thiab ua kom muaj tshuaj lom neeg.

Kev tswj dej:Hauv cov pas dej, cov pas dej thiab lwm thaj chaw dej, qis -submersible ceev tuaj yeem txhawb nqa dej kom zoo thiab tiv thaiv kev ua qias tuaj lossis tsim cov dej tuag los ntawm cov dej tsis txaus.

Kev teeb tsa

Muaj ntau yam txheej txheem kev teeb tsa siv rau kev txhim kho submersible tov khoom, Hauv qab no yog cov txheej txheem kev teeb tsa ntau tshaj plaws, thiab peb kuj tuaj yeem muab kev taw qhia rau lwm txoj kev teeb tsa.Cov txheej txheem kev teeb tsa no tuaj yeem tshem tawm lub tov khoom sai sai yam tsis muaj cov dej phwj tuaj hauv lub tank, thiab lawv muaj kev nyab xeeb thiab txhim khu kev qha.

Submersible mixer installation drawings

1. Bolts yog siv rau kev sib txuas nrog cov phab ntsa thiab hauv qab ntawm lub pas dej;
2. 2. Thov muab qhov loj ntawm H thaum xaj.

Tuam txhab Profile

VIVA-MIX yog sub-brand ntawm Henan ECO Environmental Equipment CO., Ltd.
Peb lub Hoobkas nyob hauv lub nroog keeb kwm nto moo --- Nanjing, Jiangsu Province, tshwj xeeb hauv kev tsim cov khoom siv submersible, ntsug mixers thiab aeration mechanical & devices for wastewater treatment applications. Coj los ntawm peb lub tswv yim ntawm "Technology Leads, Quality Survival," peb txuas ntxiv kawm thiab tshawb fawb cov thev naus laus zis tshiab thiab cov txheej txheem tshiab los ntawm cov khoom lag luam sab saum toj thiab thoob ntiaj teb. Los ntawm kev sib koom ua ke cov kev nce qib no nrog kev ua haujlwm ntawm qhov chaw ua haujlwm, peb tau tsim cov khoom tshwj xeeb uas sawv tawm hauv kev kho dej khib nyiab.
Peb cov khoom tseem ceeb muaj xws li lub zog -txuag submersible mixers & recirculation twj, txheem submersible mixers & recirculation twj, mixers tsim tshwj xeeb rau MBBR fillers, hyperbolic tov khoom & lwm yam paddle hom ntsug mixers, submersible (jet) aerators thiab ntau yam membrane hom cua diffuser nrog rau cov khoom siv installation. Tag nrho peb cov khoom tau raug kuaj xyuas los ntawm cov chaw kuaj xyuas lub tebchaws. Xyoo kaum xyoo dhau los, peb cov cuab yeej siv tau dav siv hauv cov chaw kho dej hauv nroog thiab cov dej khib nyiab hauv ntau qhov chaw, ua pov thawj nws cov kav ntev thiab kev lag luam kev ntseeg tau. Peb tau xa peb cov khoom mus rau ntau tshaj 100 lub teb chaws thiab cheeb tsam thiab txaus siab rau lub koob npe nrov ntawm peb cov neeg siv khoom.
Txog niaj hnub no, peb lub tuam txhab tau txais plaub qhov kev tsim tawm patents thiab nees nkaum-tsib daim qauv siv hluav taws xob, nrog cov ntawv pov thawj ntawm ISO zoo tswj qhov system, ISO ib puag ncig kev tswj hwm, ISO txoj haujlwm kev noj qab haus huv thiab kev nyab xeeb.
Kev mob siab rau kev ua tus kheej tsis tu ncua- txhim kho thiab txhim kho cov khoom lag luam, Peb tos ntsoov yuav taug kev ntawm kev tiv thaiv ib puag ncig nrog koj!

Xaiv Parameter Table

VWM 1100
Parameter
Impeller Txoj kab uas hla, mm	1100
Cov naj npawb ntawm cov hniav	2
Nominal Rotation Ceev, rpm	65/69/115/135
Tsav hom	Lub cev muaj zog + Gearbox
Lub cev muaj zog, kW	1.5/2.2/3.0/4.0
Cov khoom siv lub cev muaj zog	nrum hlau
Cov khoom siv impeller	PU/FRP
Ncej Khoom	S.S 420
Tshuab foob	Tungsten Carbide
Cov kabmob	NSK

VWM 1400
Parameter
Impeller Txoj kab uas hla, mm	1400
Cov naj npawb ntawm cov hniav	2
Nominal Rotation Ceev, rpm	55/63/65/115
Tsav hom	Lub cev muaj zog + Gearbox
Lub cev muaj zog, kW	1.5/2.2/3.0/4.0
Cov khoom siv lub cev muaj zog	nrum hlau
Cov khoom siv impeller	PU/FRP
Ncej Khoom	S.S 420
Tshuab foob	Tungsten Carbide
Cov kabmob	NSK

VWM 1600
Parameter
Impeller Txoj kab uas hla, mm	1600
Cov naj npawb ntawm cov hniav	2
Nominal Rotation Ceev, rpm	48/56
Tsav hom	Direct Drive
Lub cev muaj zog, kW	1.5/2.2/3.0/4.0
Cov khoom siv lub cev muaj zog	nrum hlau
Cov khoom siv impeller	PU/FRP
Ncej Khoom	S.S 420
Tshuab foob	Tungsten Carbide
Cov kabmob	NSK

VWM 1800
Parameter
Impeller Txoj kab uas hla, mm	1800
Cov naj npawb ntawm cov hniav	2
Nominal Rotation Ceev, rpm	42/38/56
Tsav hom	Direct Drive
Lub cev muaj zog, kW	1.5/2.2/3.0/4.0
Cov khoom siv lub cev muaj zog	nrum hlau
Cov khoom siv impeller	PU/FRP
Ncej Khoom	S.S 420
Tshuab foob	Tungsten Carbide
Cov kabmob	NSK

VWM 2200
Parameter
Impeller Txoj kab uas hla, mm	2200
Cov naj npawb ntawm cov hniav	2
Nominal Rotation Ceev, rpm	38/32/42/48
Tsav hom	Direct Drive
Lub cev muaj zog, kW	2.2/3.0/4.0/5.5
Cov khoom siv lub cev muaj zog	nrum hlau
Cov khoom siv impeller	PU/FRP
Ncej Khoom	S.S 420
Tshuab foob	Tungsten Carbide
Cov kabmob	NSK

VWM 2500
Parameter
Impeller Txoj kab uas hla, mm	2500
Cov naj npawb ntawm cov hniav	2
Nominal Rotation Ceev, rpm	38/32/42/48
Tsav hom	Direct Drive
Lub cev muaj zog, kW	2.2/3.0/4.0/5.5
Cov khoom siv lub cev muaj zog	nrum hlau
Cov khoom siv impeller	PU/FRP
Ncej Khoom	S.S 420
Tshuab foob	Tungsten Carbide
Cov kabmob	NSK
